HSD-101 H.265 H.264 1080P 60FPS Video Audio Decoder SRT HTTP RTSP RTMP UDP HLS to HD 3G SDI Converter IP Streaming to HD-SDI 3G-SDI Decoder for Decoding SDI Video Encoder and IP Camera

Model: HSD-101 HEVC & AVC SDI USB AUDIO RS485 Decoder Output: 1×SDI, 1×USB, 1×audio, 1×RS485,IO in/output Input: IP( RTMP/RTMPS/ RTSP/ RTP/ HTTP/ HLS/ UDP/SRT), MPEG2, MPEG4 Video Output Resolution: Maximum 1080 60 Fps Decoding: H.264/H.265/MPEG-1/MPEG-2/MPEG-4/VP8/VP9/AVS/AVS+ IP IN: 1, 4 Protocol: rtsp/ http/ udp/ rtmp/rtmps/srt/ hls/ rtp/p2p Audio Output: 1×3.5mm independent audio/SDI embedded audio/1×USB2.0 Format: AAC/MP3/G.711 IP Input: 1× RJ 100M/1000M, TCP, UDP System Configure: IE, remote upgrade Power: 5V~2A Consumption: 5W Size: 119mm x 102mm x 42mm working temperature: -20℃+ 60℃ working humidity: <90% Weight: 0.3KG Key features： Embedded hardware Support 4 screens at the same time Support RS485 output,IO Input/Output Control multi encoder based on one computer RTMP/ RTMPS/RTSP/ RTP/ HTTP/HTTPS/ HLS/ UDP/SRT/P2P Output: SDI/USB2.0/AUDIO/RS485/IO Up to 1080 60 FPS output Multi-IP In (1. 4). Output Up to SDI HD/3G low consumption

• Input: Up to 4K@60fps H.264/ H.265 IP (RTMP/ RTSP/ RTP/ HTTP/ HLS/ UDP), MPEG1, MPEG2, MPEG4, SL hyperlink (P-P), VP8/ VP9/ AVS/ AVS+
• Output: Up to 1080p@60fps, 1×SDI, 1×USB, 1×audio, 1×RS485, IO in/output
• Multi-IP In: Support 1 or 4 channels decoding at the same time
• Decoding Protocols: Video decoding support H.264/H.265/MPEG-1/MPEG-2/MPEG-4/VP8/VP9/AVS/AVS+, audio format support AAC/MP3/G.711.
• Additonal manufacturing Services: We are professional manufacturer. Support SDK/API,IP finder/Video management platform/IOS Android APP,Solution analyze,OEM
